Customer has asked me to demonstrate that our AOS-CX switches can replace a legacy switching solution that has NQA functionality configured to decide which of the two routes (active - standby) should route traffic. Important to note, Customer does not use dynamic routing protocols.
Reading the AOS-CX monitoring and NAE guides I concluded the same functionality that NQA delivers can be achieved by combining the functionality of IP-SLA with a NAE script (conectivity_monitor v1.1).
The way to demo to Customer was this way:
- Virtual test environment setup using the AOS-CX OVA (Virtual.10.03.0020).
![Picture1.png Picture1.png](https://higherlogicdownload.s3.amazonaws.com/HPE/MigratedInlineFiles/066b923499a4418abbe3bca0745eee1a_cabe6822d04a4193a6a7c3aef0bd4df5)
- IP-SLA configuration.
![Picture2.png Picture2.png](https://higherlogicdownload.s3.amazonaws.com/HPE/MigratedInlineFiles/066b923499a4418abbe3bca0745eee1a_774cb0dfdd714f6d936960108747d10d)
- Configuration of Agents and setup of the monitoring dashboard:
![Picture3.png Picture3.png](https://higherlogicdownload.s3.amazonaws.com/HPE/MigratedInlineFiles/066b923499a4418abbe3bca0745eee1a_c43e1e4091524a37b3464a4332838611)
The result of the demo was successful, combining IP-SLA and NAE I was able to demonstrate a routing policy based on the availability of the main - backup links.
4. Syslogs collected: ![Picture4.png Picture4.png](https://higherlogicdownload.s3.amazonaws.com/HPE/MigratedInlineFiles/066b923499a4418abbe3bca0745eee1a_e74472637395402f8129af91288be03b)
This is the video of the PoC result. Attached you will find a pdf with all the details.
(view in My Videos)
Thanks,
Adolfo
